Q-Clast – Calculiclast Workstation

Calculi-Clast1 Q-Clast – Calculiclast Workstation

About:

  • Q-Clast is a complete ureteric stone fragmentation system mounted on the ergonomically designed trolley.
  • Q-Clast consists of two major parts:
    1. Calculiclast : SME’s pneumatic lithotripter.
    2. Air compressor unit for the air supply to calculiclast.
  • Q-Clast is the stand-alone pneumatic lithotripsy system. User will not need any external air supply such as centralized oxygen or air compressor.
  • Workstation trolley has the proper platforms to keep Calculiclast control Unit as well as other related endoscopic devices.

Technical Specification:

Caluculiclast:

Control UnitPower Supply230VAC, 50Hz
Working Pressure1.8 to 4 Kg/Cm2K
Maximum input pressure6 Kg/Cm2
Pressure sourcePressurised oxygen/Compressed air
Hand PieceDimension (Dia x length)24x180mm
Weight150 gms

Workstation trolley:

Power Supply

230VAC, 50Hz

5Amp socket

2.5Amp Starting current

1.5Amp running current (Compressor on)

Dimension (H x L x W)770 x 400 x 430mm
Weight30Kg

Includes:

  1. Calculiclast Control Unit
  2. Hand Piece
  3. 5 Probes (3 URS, 1 Bladder stone and 1 PCNL)
  4. Footswitch
  5. Workstation Trolley
  6. All the necessary piping

Optional Accessories:
